Product Details
7504N19013037
# 6 x 3/8" Hex Washer Head Self Drilling Screw, Tek #2 Steel Zinc ASME B18.6.4
| Locations | Availability |
|---|---|
| METRIC THREADED PRODUCTS | Out of Stock |
7504N19013037
# 6 x 3/8" Hex Washer Head Self Drilling Screw, Tek #2 Steel Zinc ASME B18.6.4
- Log In for Price
- UM: C
- Weight: 0.0019
- Head Type and Drive: Hex Washer Head, External Hex
- Specification: ASME B18.6.4
- Thread Specifications: Self Drilling in Accordance to ASME B18.6.4
- Material and Hardness: Low Carbon Steel in Accordance to ASTM A574 for Self Drilling Screw, HRC 28-36
- Plating Finish: Clear Zinc Cr3 Trivalent Passivated
- REACH and RoHS: REACH and RoHS Compliant
- Country of Origin: Taiwan, China, Vietnam, or South Korea
- Material Test Report Available (Certification fees may apply, certificate must be requested at time of ordering)
| Product Specifications | |
|---|---|
| Diameter | # 6 |
| Thread Pitch | 20 |
| Length | 3/8" |
| Head Wd. | 1/4" |
| Head Ht. | .118" |
| Point Size | #2 |
